Canada stand up pouch packaging machine:
|
Technical data Stand up pouch packaging machine |
|
|
Type: |
Automatic Packing Machine Series |
|
Product model: |
N60S |
|
Product name: |
Canada stand up pouch packaging machine |
|
Packing speed: |
10-15 bags/min |
|
Filling range: |
100G - 1000G; accuracy:≦±0.5g/bag, depends on product |
|
Filling system: |
Electric scale |
|
Pouch material |
PE pouch, Pouch with aluminum foil |
|
Bag type: |
Stand up pouch, pouch with zipper |
|
Bag size: |
Length of Length:100~310mm,Width of Bag:100~150mm |
|
Bag socket: |
450 bags max |
|
Sealing method: |
Heat Sealing |
|
Power: |
220V, 50/60HZ, 1.5 KW |
|
Air supply: |
≧0.6Mpa, and 360L/minute (Can be equipped with Air Compressor) |
|
Weight: |
350 KG |
|
Dimension (L*W*H): |
1100*750*2100mm (L*W*H) |
|
Packing: |
2100*1100*980mm |
Thank you!
Canada stand up pouch packing machine:
1. Application: This canada stand up pouch packing machine for peanut is suitable for quantitative weighing, filling, packaging, and sealing of peanuts and various other seeds. It features a breakage-resistant filling design and is compatible with various bag types, meeting the needs of large-scale food production in Canada.
2. Applicable Bags: Stand-up zipper bags, gusseted bags, flat bags, eight-side seal bags, back seal bags, and irregularly shaped bags.
3. Bag Sizes: Bag width range: 10-20cm; Bag length range: 12-30cm.
4. Technical Parameters: Core model: HondaPack-6/8-200G; Power: 5KW; Packaging weight: 5-1500g; Measuring accuracy: ≤±1%; Packaging speed: ≤45 bags/min; Compatible with Canadian 380V 60HZ voltage; Machine weight: 500Kg; Dimensions: 1388×1116×1536mm.
5. Equipment Features: PLC computer control, bilingual (Chinese/English) touchscreen, stable operation, ability to store multiple sets of parameters, precise dual-servo film pulling, independent temperature control, compatible with food-grade packaging materials, low noise, meets Canadian industrial environmental standards, and easy changeover.
6. Export Countries: A Canadian customer purchased this stand up pouch packing machine for peanut. The equipment meets local food packaging standards, provides precise metering to meet peanut packaging needs, and can be put into production without complex modifications, helping Canadian agricultural product processing companies improve their large-scale packaging capabilities.
