Multi lane sachet packing machine - automatic honey stick sachet bag filling packing packaging machine chili sauce ketchup sachet viscous liquid packing machine:
Machine type:
Multi-lane Packaging Machine Series
Machine model:
N250
Machine name:
Multi-lane stick packing machine
Control System:
PLC + Touch screen
Packing speed:
Max 60 bag/minutes per line
Packing range:
5-40 ml per bag for granular product
Lanes:
3 Lanes
Drive way:
Vertical sealing: Pneumatic control
Horizontal sealing: Pneumatic control
Horizontal-cutting: Pneumatic control
Filling: Pneumatic control
Packing material & Thickness:
Heat seal-able packaging composite film materials, with thickness between 50 - 100micon, including: PE/aluminum coating; PE film
Diameter of film:
Inner diameter of film: 76mm / Outer diameter of film: Max 400mm
Maximum width of film:
Max 250mm for film; and max 120mm for single bag.
Maximum length of bag:
180mm long / 3.8 cm wide
Feeding system:
Cup filler system for Granule
Cutting way:
Flat cutting with notch / Zigzag cut / Round corner cut / Special shape cut;
Noise Levels of machine:
About 78dB(A)
Power supply:
Single phase, 220V, 50HZ, 3.7KW
Air supply and Air consumption:
0.6-0.8Mpa; / Air consumption: 0.8m³/min
Machine Material & Weight:
SUS304 Stainless steel for machine body & 1000KGS
Machine dimension:
1260*1550*2500mm (L*W*H)
Operating environment:
Stable flat floor, waterproof with sunshade, less than 70℃ temperature
specification:
